There's More To Vaping Than Selecting Your E-Liquid
Treat batteries badly and they’ll turn grumpy. Things that are either positive, negative and invariably jammed with lithium are a delicate affair. Batteries are important when it comes to sub-ohm vaping. No battery, no power. Finding the right battery for your device is equally important.
Get it wrong and you put a lot at risk. The quality of your experience. The frustration of Googling “why isn’t my vape working?” At the very worst, although this largely has to do with user misuse, you can run the risk of an explosion. We dedicated an entire blog post to debunking the myths surrounding “exploding vape” headlines.
Back To Basics - A Little Bit Of Battery Chemistry
Two Types (That You Need To Know)
Unless you’re stealth vaping with a mouth-to-lung (MTL) pod kit (or other starter kits that come with built-in batteries), you’ll likely be using a direct to lung (DTL) vape kit what are known as external batteries. We’re looking at you, Geek Vape Legend 3 and Voopoo Drag 5 users.
If you are using these kits or something like them, you'll likely need either a set of 18650 or 21700 batteries.
To meet the demands of hungry DTL vape kits, ordinary batteries just won't do. What you need is high density capacity and the ability to deliver high currancy efficiently and safely.
Safety is a big one. Vape batteries include built-in safety features like overcharge protection, over-discharge protection and short-circuit protection. Crucial when placing a 200W device in your mouth.
-
18650 - giving millennials a throwback to flashlight torch batteries, these are found in the vast majority of mods. The numbers simply stand for the size. 18mm diameter, 65mm height and a “0” being the battery’s way of saying: “I’m cylindrical”. On the clunky side, these are nevertheless power-pushing, long-lasting heavyweights that are used for one reason: they deliver.
-
26650 - less common and recognised by being slightly wider than 18650s, these (big surprise) are 22mm in diameter and 65mm height. Not many models take 26650s, but they’re around for powering the likes of some iJoy and Aspire devices.
Lithium-ion batteries consist of three parts: the cathode, the anode and the electrolyte. The cathode is the part giving each type its unique characteristic.
The vast majority of vape batteries are lithium ion- that’s the same kind you’ll find in your phone, laptop, cordless power tools and the remote control car you totally don’t own. There are, however, several types of lithium ion battery.
-
Lithium IMR a.k.a Li-Mn (Lithium Manganese). These are high-drain batteries that exist because manganese is awesome. Manganese allows batteries to discharge at a high current while maintaining low temperatures. Also wins points for safety and not requiring extensive built-in protective circuitry. These are currently the most-common and most-recommended type.
-
Lithium ICR a.k.a. C for Cobalt. Virtually obsolete, but still rocking the “Big Boys” image, these deliver the highest specific energy of any 18650 battery- at a cost. They’re risky to use. Few come with internal protective circuitry, so if you want this, you’ll need to fish around for added protection (third-party companies like Trustfire will do this).
Capacity, Amps And Volts (Quote This Around Other Vapers For Cred)
-
Volts, amps and ohms are something you need to understand before you start poking around for variable anything devices. All electronics have current moving along a copper wire. Think of it like water running through a pipe. How fast it’s running is the current (measured in amps). All wires also have some element of resistance to them (measured in ohms). Consider this how big the pipe is. Sub-Ohm vapers, take note. Water flows easily through a big pipe (little resistance), and less easily through a tiny pipe (high resistance). Volts are the power you’re applying to the current. Consider them the pressure in the pipes.
-
Capacity (or mAh rating) is the approximation for how long a battery charge should last from 100% to cut-off. Note. A higher rating doesn’t necessarily mean a better battery. For most, a higher amp rating (CDR or continuous discharge rate) determines better performance. CDR isn’t a suggestion. It’s the safe operating limit of the battery’s cell. It’s also a trade-off. CDR amps sacrifice mAh and run time. mAh and run time sacrifice amps and CDR. You won’t find batteries with both the highest amp rating and the highest mAh capacity. Sorry.
-
Temperature isn’t something that’s varied in the battery, per se. Temperature is the heat needed to power your device. The batteries are doing the work here, though. IMR batteries have a chemical process that can result in running a cooler battery, but the difference in battery composition has zero effect on how hot your coils (or juice) get.
Marrying Your Batteries (Without It Ending In A Brangelina)
Marrying batteries is literally what it says on the tin. Keeping the batteries together from day 1 (until death us do part). You buy them together, discharge them together, charge them together and yes, it’s important. Marrying batteries will result in longer battery life and not having one battery doing all the work.
Battery Safety
This one doesn’t get funny bits in brackets because it’s serious business. News headlines have outlined just how badly things can go if you don’t respect the basic rules of battery physics. As a rule of thumb, always follow these battery safety tips.
How Long Does a Vape Battery Last?
Short term, moderate use for an 18650 is about 6 to 12 hours. For a 21700, you're looking at 12 to 24 hours on a single charge. Of course, if you chain vape, you can expect to shave a significant amount of time off this.
The long-term lifespan of both 18650 and 21700 batteries are rated for around 300 to 500 full charges. After that their performance begins to degrade. They're still usable, they just won't hold as much charge - think of your phone as an example. An 18650 should last you between 1 to 2 years and a 21700 may potentially last for 2 to 3 years of daily use.
Again, this all depends on how you use them. Batteries that are run ragged will wear out faster. Why? It all has to do with heat and stress. When your battery has to consistently discharge power at high rates, it gets hot. This causes the internal components to wear down faster.
Heat degradation is another reason it is vital to store your batteries correctly when you're not using them, (more on that below).
Draining a battery completely is also not a good idea. Especially on a regular bases (This applies to your phones too btw). Instead of vaping until you're sucking air, try recharging your batteries before they're fully depleted. They'll thank you by living longer.
Battery Safety Do's And Dont's
-
Always use the correct charger - Most vape pens and starter kits come with their own charger. When you’re buying a more advanced device, you may have more choice when it comes to charging. If your device is compatible for micro-USB charging, do not use any old micro-USB charger. Use the one that fits your device. If you don’t know, ask. Always use a charger that is specifically compatible with your device.
-
Always use the right batteries - We’ve covered this a fair bit, but if you still have no clue which batteries are right, ask. Our staff know batteries inside out. They’ll happily recommend which ones are best.
-
Don’t cheap out - Counterfeit or poor quality batteries won’t just affect performance. They can compromise safety. Batteries aren’t something you cheap out on. Our range of batteries are high-quality, genuine and straight from trusted manufacturers.
-
Never recycle batteries - Unused lithium-ion batteries deplete charge over time. Below a certain point, they can become dangerous to use or charge. Don’t recycle these.
-
Look out for nicks or scratches - Damaged battery wraps are a hazard. Always inspect your batteries. If you see any peeling, nicks or scratches, it’s time to call it a day.
-
Never expose batteries to extreme temperatures - Batteries should never be exposed to extreme heat or cold. Don’t leave them out in 30-degree sun. Don’t stick them in the fridge.
-
Never carry loose batteries in your pocket - This is the number 1 reason for accidents. Batteries rubbing against loose coins or keys can cause a spark.
-
Don’t keep batteries charging too long - It’s not recommended to charge your batteries overnight. Basically, extended charging time will feed batteries more charge than is needed. Once the device is fully charged, unplug it.
-
Don’t exceed the amps limits - That’s like shoving an entire jar of baby food down a kid’s throat. You want to feed batteries at the rate they can handle. If you don’t know, ask.
-
Don’t pack batteries into checked luggage - Along with the million other questions on travelling with vapes, you can read our flying with vapes blog.
Don't Be The Idiot Who Winds Up With Counterfit Batteries
Seriously- don’t. There’s a very large (and very shady) market of counterfeit batteries out there. They achieve one thing. Making dishonest people rich at the expense of your own safety. If batteries seem too cheap to be true or are being sold at a roadside tattoo stand, avoid. For durability, quality, longevity and safety, always purchase batteries from a trusted vendor. You’re looking at one.
Regulated VS Unregulated Mods
It’s up to you whether you choose a regulated mod (most mods fall into this family) or an unregulated mod.
-
Regulated mods have the whistles and bells of safety. Circuit boards regulating current and control functions, power flow and built-in safety features, plus overheating and short circuit cut-off protection. Variable wattage and variable voltage mods are regulated. It’s recommended that you stick to regulated unless you’re a physics whizz.
-
Unregulated mods are just a coil wired to a battery. They’re your mech mod (which has its advantages). Not much in the way of safety features, just lots of power going straight to the atomiser. These require knowledge from set-up, to charging and maintenance.
Here’s a nerdy calculator you can use to compare battery drainage, capacity and runtime between regulated and unregulated mods.
External Charging Bays: The Best Way to Recharge a Vape Battery
As soon as you upgrade to a box mod, it’s recommended that you start charging your batteries externally. This results in faster charging time, no interference with the device and longer battery life. It’s as simple as popping the batteries into an external battery charger. We have a full range of chargers- again, ask if you’re unsure which is best.
There are endless Youtube videos that delve into microscopic battery detail- this guy is basically considered the battery god. Unfortunately, he doesn’t stock everything from nic salts to £15 starter kits, but we do.
For exclusive savings and promos before everyone else gets there, follow us on Facebook, Twitter or Instagram. We’ve got seven stores where you can try before you buy (and get boss batteries). Blog, sale, contact...yeah, we’re dedicated. Happy vaping.
